Pressure Transmitter With Current Output (2-Wire)

PT10R-2004-I2-TC11

Order ID no. 6837709

Ambient temperature max. (°C): 85
Ambient temperature min. (°C): -30
Approvals: cULus
Base unit: PCE
Connector type: PG 9
Design: Without display
Dimension unit: MMT
EAN/UPC code: 4047101431810
Electrical output: Current output (2-wire)
Electrical connection: Cable gland
Gross weight: 102
Height: 40
Housing material: Stainless-steel/Plastic
Housing quality: 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Length: 100
Material pressure transducer: Stainless steel 1.4016 (AISI 430)
Media temperature max. (°C): 135
Media temperature min. (°C): -40
Net weight: 102
Operating voltage: DC
Output function: Analog output current
Pressure range: 0...10 bar
Pressure type: Relative pressure
Process connection: G 1/4″ male thread (back sealing) according to DIN EN ISO 1179-2 with FPM profile sealing ring
Protection class: IP67
Volume: 280
Volume unit: CMQ
Weight unit: GRM
Width: 70

In Stock
List Price	A$540.08
