Pressure Transmitter With Current Output (2-Wire)
PT1V-1001-IX-H1143
Order ID no. 100015591
In Stock
List Price
A$543.30
Item Total
A$543.30
Quantity
−
+
add_shopping_cart
Add to Cart
home
Turck-Shop
Sensors
Pressure Sensors
PT1V-1001-IX-H1143
Technical Data
Downloads
Ambient temperature max. (°C)
85
Ambient temperature min. (°C)
-25
Approvals
cULus
Base unit
PCE
Connector type
M12 x 1
Design
Without display
Dimension unit
MMT
EAN/UPC code
4047101518863
Electrical output
Current output (2-wire)
Electrical connection
Connector
Gross weight
113
Height
40
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Length
100
Material pressure transducer
Ceramic Al₂O₃
Media temperature max. (°C)
120
Media temperature min. (°C)
-30
Net weight
113
Operating voltage
DC
Output function
Analog output current
Pressure range
-1...1 bar
Pressure type
Relative pressure
Process connection
G 1/4″ female thread (front sealing)
Protection class
IP67
Volume
0.28
Volume unit
DMQ
Weight unit
GRM
Width
70
Key Features
Electrical output
Current output (2-wire)
Process connection
G 1/4″ female thread (front sealing)
