Pressure Transmitter With Current Output (2-Wire)

PT10R-1104-I2-DT043P

Order ID no. 100003624

In Stock

Ambient temperature max. (°C): 100
Ambient temperature min. (°C): -40
Approvals: cULus
Base unit: PCE
Connector type: Deutsch DT04-3P
Design: Without display
Dimension unit: MMT
EAN/UPC code: 4047101482386
Electrical output: Current output (2-wire)
Electrical connection: Connector
Gross weight: 85
Height: 40
Housing material: Stainless-steel/Plastic
Housing quality: 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Length: 100
Material pressure transducer: Ceramic Al₂O₃
Media temperature max. (°C): 125
Media temperature min. (°C): -40
Net weight: 85
Operating voltage: DC
Output function: Analog output current
Pressure range: 0...10 bar
Pressure type: Relative pressure
Process connection: G 1/4″ male thread (back sealing) according to DIN EN ISO 1179-2 with FPM profile sealing ring
Protection class: IP69K
Volume: 280
Volume unit: CMQ
Weight unit: GRM
Width: 70

Electrical output: Current output (2-wire)
Process connection: G 1/4″ male thread (back sealing) according to DIN EN ISO 1179-2 with FPM profile sealing ring
