Pressure Transmitter With Voltage Output (3-Wire)

PT250R-2020-U3-H1143

Order ID no. 100000764

Ambient temperature max. (°C): 85
Ambient temperature min. (°C): -30
Approvals: cULus
Base unit: PCE
Connector type: M12 x 1
Design: Without display
Dimension unit: MMT
EAN/UPC code: 4047101442786
Electrical output: Voltage output (3-wire)
Electrical connection: Connector
Gross weight: 127
Height: 70
Housing material: Stainless-steel/Plastic
Housing quality: 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Length: 100
Material pressure transducer: Stainless steel 1.4435 (AISI 316L)
Media temperature max. (°C): 135
Media temperature min. (°C): -40
Net weight: 127
Operating voltage: DC
Output function: Analog output voltage
Pressure range: 0...250 bar
Pressure type: Relative pressure
Process connection: M20 x1.5 male thread, front sealing and manometer (combi)
Protection class: IP67
Volume: 0.28
Volume unit: DMQ
Weight unit: GRM
Width: 40

In Stock
List Price	A$540.08
