Photoelectric sensor Slot Sensor
SLM180P6Q
Order ID no. 3079215
In Stock
home
Turck-Shop
Sensors
Photoelectric Sensors
SLM180P6Q
Technical Data
Downloads
Ambient temperature max. (°C)
60
Ambient temperature min. (°C)
-20
Base unit
PCE
Connector type
M8 x 1
Design
Fork
Dimensions
140 mm x 12 mm x 202 mm
Dimension unit
MMT
EAN/UPC code
662488792152
Electrical connection
Connector
Function
Slot sensor
Gross weight
599
Height
45
Housing material
Metal
Housing quality
Zinc Die-Cast with Nickel-Plating
Length
240
Light type
Red
Max. range (mm)
180
Net weight
599
Operating mode
Emitter/receiver pair
Output function
PNP
Protection class
IP67
Setting option
Potentiometer
Switching element function
normally open NO
Volume
2268
Volume unit
CMQ
Wavelength (nm)
680
Weight unit
GRM
Width
210
Key Features
Light type
Red
Function
Slot sensor
Output function
PNP
Max. range (mm)
180
List Price
A$517.42
Item Total
A$517.42
