QMH26VPAF400Q7 | TURCK - Your Global Automation Partner
Photoelectric sensor Diffuse-Mode Sensor with Adjustable Background Suppression
QMH26VPAF400Q7
Order ID no. 3028787
home
Home
Loading...
Technical Data
Downloads
Ambient temperature max. (°C)
70
Ambient temperature min. (°C)
-30
Base unit
PCE
Connector type
M8 x 1
Design
Rectangular
Dimensions
20,3 mm x 14 mm x 32,6 mm
Dimension unit
MMT
EAN/UPC code
662488287870
Electrical connection
Connector
Function
Proximity switch
Gross weight
62
Height
40
Housing material
Metal
Housing quality
Stainless steel
Housing surface
Grey
Length
90
Light type
Red
Max. range (mm)
400
Net weight
62
Operating mode
Background suppression, adjustable
Output function
PNP
Protection class
IP69
Setting option
Screw Adjustment
Special features
Chemical-resistant, Resistant to chemicals, Wash down
Switching element function
Complementary contact
Switching frequency (kHz)
2
Volume
180
Volume unit
CMQ
Wavelength (nm)
620
Weight unit
GRM
Width
50
home
Turck-Shop
Sensors
Photoelectric Sensors
QMH26VPAF400Q7
Key Features
Light type
Red
Function
Proximity switch
Output function
PNP
Max. range (mm)
400
In Stock
List Price
A$807.27
Item Total
A$807.27
Quantity
−
+
add_shopping_cart
Add to Cart
Contact Support
