QM26VPRQ5 | TURCK - Your Global Automation Partner
Photoelectric sensor Opposed Mode Sensor (Receiver)
QM26VPRQ5
Order ID no. 3028714
home
Home
Loading...
Technical Data
Downloads
Ambient temperature max. (°C)
70
Ambient temperature min. (°C)
-30
Base unit
PCE
Cable length (m)
0.2
Connector type
M12 x 1
Design
Rectangular
Dimensions
15,3 mm x 14 mm x 32,6 mm
Dimension unit
MMT
EAN/UPC code
662488287146
Electrical connection
Cable with connector
Function
Opposed mode sensor
Gross weight
72
Height
40
Housing material
Metal
Housing quality
Stainless steel
Housing surface
Grey
Length
80
Max. range (mm)
8500
Net weight
72
Operating mode
Receiver
Output function
PNP
Protection class
IP69
Special features
Chemical-resistant, Resistant to chemicals, Wash down
Switching element function
Complementary contact
Switching frequency (kHz)
2
Volume
160
Volume unit
CMQ
Wavelength (nm)
620
Weight unit
GRM
Width
50
Key Features
Function
Opposed mode sensor
Output function
PNP
Max. range (mm)
8500
