BI10-EM30-AP6/S907 | TURCK - Your Global Automation Partner
Inductive Sensor With Increased Temperature Range
BI10-EM30-AP6/S907
Order ID no. 4614513
home
Home
Loading...
Technical Data
Downloads
CAD
Ambient temperature max. (°C)
160
Ambient temperature min. (°C)
-25
Base unit
PCE
Cable length (m)
2
Design
Threaded barrel
Dimension unit
MMT
EAN/UPC code
4047101170504
Electrical connection
Cable
Gross weight
322
Height
30
Housing diameter (mm)
⌀ 30 mm
Housing material
Stainless steel
Housing quality
1.4571 (AISI 316Ti)
Length
150
Mounting conditions
Flush
Net weight
322
Operating voltage
DC
Output function
PNP
Protection class
IP68, IP69K
Quality active face
PEEK
Rated switching distance (mm)
10
Special features
Pressure resistant
Switching element function
normally open NO
Switching frequency (kHz)
0.2
Volume
675
Volume unit
CMQ
Weight unit
GRM
Width
150
Key Features
Electrical connection
Cable
Mounting conditions
Flush
Output function
PNP
Rated switching distance (mm)
10
