Inductive Sensor With Extended Switching Distance
BI3-M08K-AN6X-V1131
Order ID no. 4602935
home
Home
Loading...
Technical Data
Downloads
CAD
Ambient temperature max. (°C)
70
Ambient temperature min. (°C)
-25
Base unit
PCE
Connector type
M8 x 1
Design
Threaded barrel
Dimension unit
MMT
EAN/UPC code
4047101403473
Electrical connection
Connector
Gross weight
17
Height
10
Housing diameter (mm)
⌀ 8 mm
Housing material
Metal
Housing quality
CuZn
Housing surface
Nickel Plated
Length
100
Mounting conditions
Flush
Net weight
17
Operating voltage
DC
Output function
NPN
Protection class
IP67
Quality active face
PP-GF20
Rated switching distance (mm)
3
Special features
Sn +
Switching element function
normally open NO
Switching frequency (kHz)
2.8
Volume
100
Volume unit
CMQ
Weight unit
GRM
Width
100
home
Turck-Shop
Sensors
Inductive Sensors
BI3-M08K-AN6X-V1131
Key Features
Electrical connection
Connector
Mounting conditions
Flush
Output function
NPN
Rated switching distance (mm)
3
