REI-E-112I8T-2B1024-C | TURCK - Your Global Automation Partner
Incremental Encoder
REI-E-112I8T-2B1024-C
Order ID no. 100012013
home
Home
Loading...
Technical Data
Downloads
Ambient temperature max. (°C)
70
Ambient temperature min. (°C)
-20
Base unit
PCE
Design
Hollow shaft
Dimension unit
MMT
EAN/UPC code
4047101545807
Electrical connection
Cable
Encoder line
Efficiency-Line
Flange diameter (mm)
40
Flange type
Flange with mounting element
Gross weight
255
Height
90
Housing material
Aluminium
Length
100
Measuring principle
Optical
Net weight
255
Output function
Push-Pull/HTL
Output type
Incremental
Protection class
IP64
Protection class shaft
IP64
Resolution incremental (ppr)
1024
Shaft diameter D (mm)
8 mm
Shaft Type
Blind hole shaft
Technology
Optical
Volume
0.009
Volume unit
HLT
Weight unit
GRM
Width
100
home
Turck-Shop
Sensors
Encoders
REI-E-112I8T-2B1024-C
Key Features
Output type
Incremental
Flange diameter (mm)
40
Shaft diameter D (mm)
8 mm
Shaft Type
Blind hole shaft
In Stock
List Price
A$395.93
Item Total
A$395.93
