REI-E-111T6C-2B100-C | TURCK - Your Global Automation Partner
Incremental Encoder
REI-E-111T6C-2B100-C
Order ID no. 100011940
home
Home
Loading...
Technical Data
Downloads
Ambient temperature max. (°C)
70
Ambient temperature min. (°C)
-20
Base unit
PCE
Design
Solid shaft
Dimension unit
MMT
Electrical connection
Cable
Encoder line
Efficiency-Line
Flange diameter (mm)
40
Flange type
Synchro/clamping flange
Gross weight
244
Height
95
Housing material
Aluminium
Length
100
Measuring principle
Optical
Net weight
244
Output function
Push-Pull/HTL
Output type
Incremental
Protection class
IP64
Protection class shaft
IP64
Resolution incremental (ppr)
100
Shaft diameter D (mm)
6 mm
Shaft Type
Solid shaft
Technology
Optical
Volume
0.997
Volume unit
DMQ
Weight unit
GRM
Width
105
home
Turck-Shop
Sensors
Encoders
REI-E-111T6C-2B100-C
Key Features
Output type
Incremental
Flange diameter (mm)
40
Shaft diameter D (mm)
6 mm
Shaft Type
Solid shaft
In Stock
List Price
A$395.93
Item Total
A$395.93
