HT-WWAK3-15/S2430 | TURCK - Your Global Automation Partner
arrow_back_ios
arrow_forward_ios
High-Temperature Resistant Actuator and Sensor Cable Connection Cable
HT-WWAK3-15/S2430
Order ID no. 8104902
home
Home
Loading...
Technical Data
Downloads
Application
Signal
Base unit
PCE
Cable color
White
Cable diameter (mm)
3.8
Cable length (m)
15
Cable quality
PTFE
Connector A
Female, M12 x 1, Angled
Core cross-section (mm²)
0.34
Coupling nut/screw material A
Brass
Current (A)
4
Design
Connection Cable
Dimension unit
MMT
EAN/UPC code
4047106292812
Gross weight
524
Height
40
Length
150
Net weight
524
Number of pins
3
Plug body
Plastic
Special features
High temperature, Resistant to welding sparks
Voltage (V)
250
Volume
0.009
Volume unit
HLT
Weight unit
GRM
Width
150
Key Features
Cable length (m)
15
Cable quality
PTFE
home
Turck-Shop
Connectivity
Cordsets
HT-WWAK3-15/S2430
In Stock
