High-Temperature Resistant Actuator and Sensor Cable Connection Cable
HT-WAK4-10/S2430
Order ID no. 8036154
In Stock
home
Turck-Shop
Connectivity
Cordsets
HT-WAK4-10/S2430
Technical Data
Downloads
Application
Signal
Base unit
PCE
Cable color
White
Cable diameter (mm)
3.8
Cable length (m)
10
Cable quality
PTFE
Connector A
Female, M12 x 1, Straight
Core cross-section (mm²)
0.34
Coupling nut/screw material A
Brass
Current (A)
4
Design
Connection Cable
Dimension unit
MMT
EAN/UPC code
4047106147624
Gross weight
334
Height
20
Length
170
Net weight
334
Number of pins
4
Plug body
Plastic
Special features
High temperature, Resistant to welding sparks
Voltage (V)
250
Volume
578
Volume unit
CMQ
Weight unit
GRM
Width
170
Key Features
Cable length (m)
10
Cable quality
PTFE
Quantity
−
+
add_shopping_cart
Add to Cart
Contact Support
