Actuator and Sensor Cable, PVC Connection Cable
PSW4M-5/TEY
Order ID no. 6630128
home
Home
Loading...
Technical Data
Downloads
Ambient temperature max. (°C)
80
Ambient temperature min. (°C)
-5
Application
Signal
Approvals
cULus
Base unit
PCE
Cable color
Yellow
Cable diameter (mm)
4.6
Cable length (m)
5
Cable quality
PVC
Connector A
Male, M8 x 1, Angled
Core cross-section (mm²)
0.34
Coupling nut/screw material A
Brass
Current (A)
4
Design
Connection Cable
Dimension unit
MMT
EAN/UPC code
4047101363524
Gross weight
193
Height
20
Length
200
Net weight
193
Number of pins
4
Plug body
Plastic
Volume
0.006
Volume unit
HLT
Weight unit
GRM
Width
150
home
Turck-Shop
Connectivity
Cordsets
PSW4M-5/TEY
Key Features
Cable length (m)
5
Cable quality
PVC
In Stock
List Price
A$35.49
Item Total
A$35.49
