Actuator and Sensor Cable, PVC Connection Cable
PKGV3M-8/TEL
Order ID no. 100000372
home
Home
Loading...
Technical Data
Downloads
Ambient temperature max. (°C)
80
Ambient temperature min. (°C)
-5
Application
Signal
Approvals
cULus
Base unit
PCE
Cable color
Black
Cable diameter (mm)
4.3
Cable length (m)
8
Cable quality
PVC
Connector A
Female, M8 x 1, Straight
Core cross-section (mm²)
0.34
Coupling nut/screw material A
Stainless Steel
Current (A)
4
Design
Connection Cable
Dimension unit
MMT
EAN/UPC code
4047101437737
Gross weight
257
Height
20
Length
180
Net weight
257
Number of pins
3
Plug body
Plastic
Volume
0.576
Volume unit
DMQ
Weight unit
GRM
Width
160
Key Features
Cable length (m)
8
Cable quality
PVC
