Temperature Detection
TS-530-LI2UPN8X-H1141-L016
Order ID no. 6840027
In Stock
Price Group
D2
List Price
A$913.68
home
Turck-Shop
Sensors
Temperature Sensors
TS-530-LI2UPN8X-H1141-L016
Technical Data
Switching element function
NO/NC programmable
Output function
PNP/NPN
Communication protocol
IO-Link
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Stainless-steel/Plastic
Housing quality
1.4305 (AISI 303)
Ambient temperature min. (°C)
-40
Ambient temperature max. (°C)
80
Protection class
IP67, IP69K
Design
With display (integrated probe)
Detection type
medium contact
Immersion depth L (mm)
16
Process connection
1/2″ NPT male thread
Electrical output
Current output (3-wire), Switching output
Operating voltage
DC
Measuring range
-50…150 °C
Key Features
Communication protocol
IO-Link
Electrical output
Current output (3-wire), Switching output
Process connection
1/2″ NPT male thread
Measuring range
-50…150 °C
