Pressure Transmitter
PT5000PSIG-2005-I2-DA91
Order ID no. 6837338| In Stock | |
| List Price | A$517.81 |
Item TotalA$517.81
Quantity
- Protection class
- IP65
- Output function
- Analog output current
- Approvals
- cULus
- Design
- Without display
- Process connection
- 7/16″-20 UNF male thread
- Electrical connection
- Connector
- Connector type
- DIN EN 175301-803 Form A
- Housing material
- Stainless-steel/Plastic
- Housing quality
- 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
- Media temperature min.
- -40
- Media temperature max.
- 135
- Ambient temperature min.
- -30
- Ambient temperature max.
- 85
- Operating voltage
- DC
- Electrical output
- Current output (2-wire)
- Pressure type
- Relative pressure
- Material pressure transducer
- Stainless steel 1.4435 (AISI 316L)
- Pressure range
- 0…344.74 bar
Key Features
- Electrical output
- Current output (2-wire)
- Process connection
- 7/16″-20 UNF male thread
- Pressure range
- 0…344.74 bar
