PS025D-501T-LI2UPN8X-H1141 | TURCK - Your Global Automation Partner
Differential Pressure Sensor
PS025D-501T-LI2UPN8X-H1141
Order ID no. 6834066
home
Home
Loading...
Technical Data
Switching element function
NO/NC
Output function
PNP/NPN
Communication protocol
IO-Link
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Stainless-steel/Plastic
Housing quality
1.4305 (AISI 303)
Ambient temperature min. (°C)
-40
Ambient temperature max. (°C)
80
Protection class
IP67, IP69K
Design
With display
Process connection
G 1/4'' female thread
Electrical output
2 × switching output
Min. media temperature (°C)
-40
Max. media temperature (°C)
85
Operating voltage
DC
Pressure transducer material
Ceramic Al₂O₃
Pressure range
0…25 bar
Pressure type
Differential Pressure
Key Features
Communication protocol
IO-Link
Electrical output
2 × switching output
Process connection
G 1/4'' female thread
Pressure range
0…25 bar
home
Turck-Shop
Sensors
Pressure Sensors
PS025D-501T-LI2UPN8X-H1141
Item Total
A$1,627.35
Quantity
−
+
add_shopping_cart
Add to Cart
In Stock
List Price
A$1,627.35
Contact Support
