Pressure Sensor

PS325-10D-04-LI2UPN8-H1141

Order ID no. 100041104

Switching element function: NO/NC
Output function: PNP/NPN
Communication protocol: IO-Link
Electrical connection: Connector
Connector type: M12 × 1
Housing material: Stainless-steel/Plastic
Housing quality: 1.4404 (AISI 316L)/Grilamid TR90 UV
Ambient temperature min. (°C): -40
Ambient temperature max. (°C): 80
Protection class: IP66, IP67, IP69K
Design: With display (integrated probe)
Process connection: G 1/4'' male thread (BSP)
Electrical output: Switching output, Current output (3-wire), Voltage output (3-wire), IO-Link
Min. media temperature (°C): -30
Max. media temperature (°C): 80
Pressure range: 0…10 bar
Pressure type: Differential Pressure
Approvals: cULus

Communication protocol: IO-Link
Electrical output: Switching output, Current output (3-wire), Voltage output (3-wire), IO-Link
Process connection: G 1/4'' male thread (BSP)
Pressure range: 0…10 bar
