Pressure Transmitter
PT50R-2149-U6-DT043P
Order ID no. 100030750| In Stock | |
| List Price | A$547.79 |
Item TotalA$547.79
Quantity
- Protection class
- IP69K
- Output function
- ratiom. 10…90%
- Design
- Without display
- Process connection
- G 3/8'' male thread
- Electrical connection
- Connector
- Connector type
- Deutsch DT04-3P
- Housing material
- Stainless-steel/Plastic
- Housing quality
- 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
- Media temperature min. (°C)
- -40
- Media temperature max. (°C)
- 125
- Ambient temperature min. (°C)
- -40
- Ambient temperature max. (°C)
- 100
- Operating voltage
- DC
- Electrical output
- Voltage output (3-wire)
- Pressure type
- Relative pressure
- Material pressure transducer
- Stainless steel 1.4404 (AISI 316L)
- Pressure range
- 0…50 bar
Key Features
- Electrical output
- Voltage output (3-wire)
- Process connection
- G 3/8'' male thread
- Pressure range
- 0…50 bar
