PT600R-2110-I2-AMP3J1 | TURCK - Your Global Automation Partner
Pressure Transmitter
PT600R-2110-I2-AMP3J1
Order ID no. 100003587
home
Home
Loading...
Technical Data
Output function
Analog output current
Electrical connection
Connector
Connector type
AMP JPT
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Ambient temperature min. (°C)
-40
Ambient temperature max. (°C)
100
Protection class
IP67
Design
Without display
Process connection
R 1/4″ male thread EN 10226
Electrical output
Current output (2-wire)
Min. media temperature (°C)
-40
Max. media temperature (°C)
125
Operating voltage
DC
Pressure transducer material
Stainless steel 1.4404 (AISI 316L)
Pressure range
0…600 bar
Pressure type
Relative pressure
Approvals
cULus
Key Features
Electrical output
Current output (2-wire)
Process connection
R 1/4″ male thread EN 10226
Pressure range
0…600 bar
In Stock
List Price
A$547.79
