Pressure Transmitter
PT7500PSIG-2119-U6-DT043P
Order ID no. 100002958| In Stock | |
| Price Group | J1 |
| List Price | A$474.86 |
Item TotalA$474.86
Quantity
- Output function
- ratiom. 10…90%
- Electrical connection
- Connector
- Connector type
- Deutsch DT04-3P
- Housing material
- Stainless-steel/Plastic
- Housing quality
- 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
- Ambient temperature min. (°C)
- -40
- Ambient temperature max. (°C)
- 100
- Protection class
- IP69K
- Design
- Without display
- Process connection
- M14 × 1.5 male thread
- Electrical output
- Voltage output (3-wire)
- Min. media temperature (°C)
- -40
- Max. media temperature (°C)
- 125
- Operating voltage
- DC
- Pressure transducer material
- Stainless steel 1.4404 (AISI 316L)
- Pressure range
- 0…517.11 bar
- Pressure type
- Relative pressure
- Approvals
- cULus
Key Features
- Electrical output
- Voltage output (3-wire)
- Process connection
- M14 × 1.5 male thread
- Pressure range
- 0…517.11 bar
