Absolute Rotary Encoder - Single-Turn
RES-181BA0T-8BAR-H1151/N0
Order ID no. 100016373| In Stock | |
| Price Group | F3 |
| List Price | A$1,286.30 |
Item TotalA$1,286.30
Quantity
- Output function
- Analog output
- Electrical connection
- Connector
- Connector type
- M12 × 1
- Housing material
- Die-cast zinc
- Ambient temperature min. (°C)
- -40
- Ambient temperature max. (°C)
- 85
- Protection class
- IP67
- Measuring principle
- Magnetic
- Measuring range
- 0…360°
- Output type
- Absolute singleturn
- Flange type
- Flange with mounting element
- Shaft Type
- Blind hole shaft
- Flange diameter (mm)
- 36
- Shaft diameter D (mm)
- 6.35
Key Features
- Output type
- Absolute singleturn
- Flange diameter (mm)
- 36
- Shaft diameter D (mm)
- 6.35
- Shaft Type
- Blind hole shaft
