Absolute Rotary Encoder - Multiturn
REM-98B8E-7AAR-H1151
Order ID no. 100011328| In Stock | |
| List Price | A$1,230.98 |
Item TotalA$1,230.98
Quantity
- Protection class
- IP67
- Output function
- Analog output
- Electrical connection
- Connector
- Connector type
- M12 × 1
- Housing material
- Die-cast zinc
- Ambient temperature min.
- -40
- Ambient temperature max.
- 85
- Measuring principle
- Magnetic
- Output type
- Absolute multiturn
- Shaft Type
- Blind hole shaft
- Shaft diameter D (mm)
- 8
- Flange diameter
- 46
- Flange type
- Flange with stator coupling
Key Features
- Output type
- Absolute multiturn
- Flange diameter
- 46
- Shaft diameter D (mm)
- 8
- Shaft Type
- Blind hole shaft
