REI-10S6C-4B360-H1181
REI-10S6C-4B360-H1181
Thumbnail for REI-10S6C-4B360-H1181
Thumbnail for REI-10S6C-4B360-H1181

Incremental Encoder

REI-10S6C-4B360-H1181

Order ID no. 100010252
In Stock
List PriceA$959.47
Item TotalA$959.47
Quantity
Protection class
IP67
Output function
RS422/TTL
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Die-cast zinc
Ambient temperature min.
-40
Ambient temperature max.
85
Measuring principle
Optical
Output type
Incremental
Shaft Type
Solid shaft
Shaft diameter D (mm)
6
Flange diameter
58
Flange type
Clamping flange
Resolution, incremental
360

Key Features

Output type
Incremental
Flange diameter
58
Shaft diameter D (mm)
6
Shaft Type
Solid shaft
