Isolating switching amplifier

IM12-22EX-R/230VAC

Order ID no. 7505641

Electrical connection: 4 × 3-pin removable terminal blocks, reverse polarity protected, screw terminal
Housing material: Plastic
Housing quality: Polycarbonate/ABS
Ambient temperature min. (°C): -25
Ambient temperature max. (°C): 60
Protection class: IP20
Number of channels: 2
Ex version: yes
Power supply: 230 VAC
Signal type: Digital input
Nominal voltage: 230 VAC
Approvals: ATEX, TR CU
Approvals: ATEX, TR CU
Digital output: Relay output
