Compact Multiprotocol RFID Module for Ethernet
TBEN-L4-4RFID-8DXP
Order ID no. 100002462| In Stock | |
| Price Group | D1 |
| List Price | A$3,281.74 |
Item TotalA$3,281.74
Quantity
- Cable length (m)
- 50
- Ambient temperature min. (°C)
- -40
- Ambient temperature max. (°C)
- 70
- Protection class
- IP65, IP67, IP69K
- Network protocol
- Modbus TCP, EtherNet/IP, PROFINET
- Operating voltage
- DC
- Connection technology signal
- M12
- Number of channels
- 12
- Signal type
- RFID, Digital input, Digital input/output, Digital output
- Approvals
- ATEX Zone 2/22, cULus
- Connection technology Ethernet
- 2 x M12, 4-pin, D-coded
- Transmission rate Ethernet
- 10/100 Mbps
- Installation area
- non-Ex
- Output voltage
- 24 VDC from potential group
Key Features
- Network protocol
- Modbus TCP, EtherNet/IP, PROFINET
- Number of channels
- 12
- Protection class
- IP65, IP67, IP69K
