Identification

ABR3009-WSE2

Order ID no. 3804427

Function: Barcode reader - scanner
Light type: White
Resolution (Pixel): 752 x 480
Switching element function: NO/NC
Output function: PNP/NPN
Communication protocol: EtherNet/IP, FTP, Modbus TCP, PROFINET, RS232, RS422
Electrical connection: Connector
Connector type: M12 × 1
Cable length (m): 1
Housing material: Metal
Housing quality: AL
Ambient temperature min. (°C): 0
Ambient temperature max. (°C): 45
Protection class: IP65
Design: Rectangular
Operating voltage: DC
Focal distance (mm): 9

Communication protocol: EtherNet/IP, FTP, Modbus TCP, PROFINET, RS232, RS422
Focal distance (mm): 9
Light type: White
Resolution (Pixel): 752 x 480
